Air-sprung fork? Let me introduce you to your new friend, Judy. Discerning when it comes to your drivetrain? You'll find no fault—and no grade too steep—with a wide-range Shimano Deore 1x10 drivetrain. Why stop there? We didn't, in order to allow you the pleasure of stopping yourself with Shimano's eager-to-please and oh-so-capable MT200 hydraulic disc brakes.
Each is impressive in their own right, but the magic really lies in how they all come together into a Rockhopper that serves up singletrack with a nice big side of ' Whoah, so that's what a real bike feels like.'
-----------------------------------------------------------------------------------------------------------------
| Frame | A1 premium butted alloy, zero-stack head tube, internal cable routing, 135x9mm forged dropouts, chainstay-mounted disc brake, replaceable alloy derailleur hanger, stealth rack mounts, dropper post compatible |
| Seat Binder | Alloy, quick release, 34.9 |
| Rear Derailleur | Shimano Deore, Shadow Plus, GS cage, 10-speed |
| Chain | KMC, X10, EPT anti-corrosion coating, 10-speed w/ Missing Link™ |
| Bottom Bracket | Square-tapered, 73mm, internal bearings, 122.5mm spindle |
| Shift Levers | Shimano Deore, RapidFire Plus, 10-speed w/ Optical Gear Display |
| Crankset | Stout 1x, forged alloy |
| Cassette | SunRace, 11-42t, 10-speed |
| Rear Tire | Ground Control, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3" |
| Inner Tubes | Presta, 40mm valve |
| Front Tire | Ground Control, Control casing, GRIPTON® compound, 60 TPI, 2Bliss Ready, 29x2.3" |
| Front Hub | Shimano HB-RM35, Center Lock™ disc, 9x100mm spacing, quick-release, 28h |
| Rear Hub | Shimano FH-RM35, Center Lock™ disc, 9x135mm spacing, quick-release, 32h |
| Rims | Alloy, Offset Design, Tubeless Ready, 25mm internal width, 28h |
| Fork | RockShox Judy, Solo Air, Turnkey damper, 46mm offset, QR, 80/90/100mm travel (size-specific), steel steerer |
| Grips | Specialized Trail Grips, lock-on |
| SeatPost | Alloy, 12mm offset, 2-bolt clamp, 30.9mm |
| Saddle | Bridge Sport, steel rails |
| Handlebars | Stout Mini Rise, alloy, 9-degree backsweep, 15mm rise, 31.8mm |
| Stem | Stout 3D-forged alloy, 31.8mm, 6-degree rise |
| Spokes | Stainless, 14g |
| Front Brake | Shimano BR-MT200, hydraulic disc, 180mm |
| Rear Brake | Shimano BR-MT200, hydraulic disc, 160mm |
| Pedals |
| S | M | L | XL | XXL | |
|---|---|---|---|---|---|
| Crank Length | 170mm | 170mm | 175mm | 175mm | 175mm |
| Stem Length | 45mm | 60mm | 60mm | 70mm | 70mm |
| Seatpost Length | 350mm | 400mm | 400mm | 400mm | 400mm |
| Saddle Width | 155mm | 143mm | 143mm | 143mm | 143mm |
| Handlebar Width | 720mm | 740mm | 740mm | 740mm | 740mm |
| Reach | 405mm | 425mm | 445mm | 465mm | 485mm |
| Stack | 607mm | 616mm | 626mm | 640mm | 654mm |
| Wheelbase | 1105mm | 1128mm | 1152mm | 1178mm | 1203mm |
| Bike Stand-Over Height | 732mm | 754mm | 781mm | 820mm | 853mm |
| Head-Tube Length | 95mm | 95mm | 105mm | 120mm | 135mm |
| Front-Center | 672mm | 696mm | 719mm | 745mm | 770mm |
| Fork Rake/Offset | 46mm | 46mm | 46mm | 46mm | 46mm |
| Head-Tube Angle | 68.5° | 68.5° | 68.5° | 68.5° | 68.5° |
| Trail | 97mm | 97mm | 97mm | 97mm | 97mm |
| B-B Height | 310mm | 310mm | 310mm | 310mm | 310mm |
| Chain-Stay Length | 440mm | 440mm | 440mm | 440mm | 440mm |
| Fork Length (Full) | 505mm | 515mm | 515mm | 515mm | 515mm |
| Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| B-B Drop | 62mm | 62mm | 62mm | 62mm | 62mm |
| Seat-Tube Length | 360mm | 400mm | 450mm | 500mm | 560mm |
| Top-Tube Length (Horizontal) | 586mm | 608mm | 630mm | 654mm | 679mm |
